CHAIN CONVEYOR
- Optimized conveying speed,
- Specially designed chain of higher strength and breaking load with heat treatment,
- Bush mad of (EN8/EN9) steel,
- Chain guide roller with bearings,
- Rails provided for return chain,
- Capacity Based on grain bulk density 720Kg/m3
- Abrasion Resistant liner of UHMWPE (Ultra High Molecular Weight Poly Ethylene) at the bottom,
- Leak proof top cover for the conveyor specially designed to drain off rain water,
- Provision for multiple inlets and outlets,
- Long Life and trouble free operation,
- Capacity above 200 TPH available on demand,
Standard Chain Conveyor (CC) Models
| Sr. No. | Chain Conveyor Models | Width of Chain Conveyor Casing (mm) | Chain Flight size in mm | Chain Speed in Mtr./sec. | Chain Conveyor capacity in TPH |
|---|---|---|---|---|---|
| 1 | CC – 150 | 150 | 45 | 0.6 | 15 |
| 2 | CC – 200 | 200 | 45 | 0.8 | 30 |
| 3 | CC – 250 | 250 | 45 | 0.9 | 45 |
| 4 | CC – 300 | 300 | 65 | 0.85 | 75 |
| 5 | CC – 400 | 400 | 65 | 1.20 | 150 |
| 6 | CC – 550 | 550 | 65 | 1.20 | 250 |
All Steel components like Top Hood, Bottom Boot, and casing made of bolted construction are cut on laser machine.
